Need to see without being seen? Discover the CARPATIA swing gate with its sloping louvered slats.
Discover the CARPATIA semi-openwork gate, combining modernity and ingenuity with its sloping louvered slats. This design allows you to see outside without being seen, while providing optimal protection for your privacy. The clean horizontal lines reinforce the contemporary look of this collection, ideal for those looking for an aluminum swing gate that offers both discretion and elegance.
Swing Gate: The ideal solution for a spacious and secure entrance
With its classic two-leaf opening, the swing gate combines elegance and practicality. Ideal for spacious entrances, it offers easy access while adding a touch of style to your exterior. Robust and durable, it is weather-resistant, ensuring a long lifespan. Easy to maintain, it is a reliable and attractive solution for securing your property. If you choose a double-leaf gate motor, this will further increase its ease of use, making it easier to open and close your electric swing gate on a daily basis.
This swing gate has a wind resistance of 55 km/h.
Material: Aluminum Color: Anthracite Gray - RAL 7016 Dimensions: Width 300 cm x Height 176 cm Compatible space between posts: 351.5 cm to 357.5 cm Minimum post height: 190 cm
This kit contains: - 2 reinforced slats to motorize your gate - 2 upper hinges mounted on ball bearings - 2 lower hinges - 1 cylinder lock - 5 keys - 1 automatic center stop - 2 receiving stops - Hardware
About the Material
Aluminum stands out for its lightness, strength, and corrosion resistance. This material does not rust and retains its appearance over time, even in the face of adverse weather conditions. Easy to maintain, simple regular cleaning is enough to preserve its original shine. Durable and attractive, aluminum is ideal for your outdoor spaces, offering a modern and high-performance solution. By choosing aluminum, you combine practicality, longevity, and elegance every day.
Are posts included?
Our kits do not include posts, as they are not always necessary. If you already have posts in place, installation is possible without adding any additional materials. For those who need them, we offer value packs with compatible posts. The minimum height of the posts for this swing gate is 190 cm.
How should I maintain my aluminum product?
Aluminum requires very little maintenance. To maintain its shine and durability, clean it once or twice a year with warm, soapy water and a soft cloth. Rinse and dry thoroughly, and avoid abrasive products or high-pressure cleaning, which could damage the powder coating.
Need help choosing your swing gate? Contact our customer service via our online form.
The TANKER B250 actuator is ideal for motorizing swing gates up to 5 meters long and weighing up to 600 kg (2.5 meters and 300 kg maximum per leaf).
Specially designed for swing gates, this actuator allows you to motorize any type of swing gate, whether new or existing, made of iron, aluminum, PVC, or wood.
Its simple and discreet design allows you to enjoy an electric gate that's easy to use without compromising the aesthetics of your gate or detracting from your exterior.
This actuator consists of two actuator arms, each designed to motorize one leaf of your gate. The pistons located inside the actuators extend to close the gate and retract to open it.
Supplied with clear and detailed installation instructions, you can motorize your gate quickly and easily! Our installation instructions have been designed to guide you step by step through the proper operation of your automation system, using clear instructions accompanied by illustrations to facilitate your understanding.
If you need help or encounter difficulties, our Casanoov technical team is here to assist you.
We also invite you to watch our tutorial video available at the bottom of this product sheet in the "Videos" tab. This video has been specially designed to guide you through each step of installing your motor.
This kit contains: - 2 motors with an electrical voltage of 24 Volts / 60 Watts - A control box - A central gate stop - 2 post mounting brackets allowing for multiple opening angle configurations - 2 mounting brackets to attach your motor to your swing gate - 2 4-button remote controls with protective cover (Batteries included) - A set of screws to attach the motor to your posts - 1 flashing LED light with a power of 3 Watts (equivalent to a power of 30W for an old-generation incandescent bulb) - 1 pair of infrared photocells with the following characteristics:
Accessories not included with the B250 motor: Screws to secure the motor to the gate. These screws must be adapted to each gate type and chosen according to the thickness of your gate. For Casanoov Swing gates, we recommend securing your motor arms with Rivkle blind rivets between 8 and 12 mm long. The mounting bracket must be positioned on the reinforced slats provided for this purpose on all our swing gates and wickets.
Features of the TANKER B250 motor:
- Inward and outward opening - Opening angle between 90° and 110° - The opening angle is determined by your installation requirements. (You will find all the installation instructions in the instructions, which can be downloaded freely from the product page) - Manual motor release in case of power outage - Retracted product length: 78 cm - Open product length: 105 cm - Arm working length: 39 cm - Arm opening speed: 2.5 cm/second, or approximately 15 seconds - Internal rotation speed: 300 RPM (Revolutions per minute), or 50% faster than the B150 model! - Opening performance can vary using the soft opening and closing mode. - The opening and closing speed, as well as the drive power, can be adjusted to 20 different positions. - After opening, the gate can close automatically according to your chosen time interval, ranging from 0 to 99 seconds. - Pedestrian mode: You can choose to open only one of the two leaves. - Rain protection class: IP 55. - Weight of each motor: 17 kg. - Operating temperature: -20°C to +50°C. - Thrust force: 1090N to 1110N. - Electrical connection between your home and the motor: 220VAC±10%/110VAC±10%. - Auto-stop function: If your gate encounters an obstacle, the opening or closing of the gate stops automatically.
You can combine external accessories with a 24V operating power, such as a backup battery, magnetic or electric lock, or push button.
The gate stop should be used if you have a swing gate stop for a manual gate. When you motorize your swing gate, you must ensure that the central stop does not hold it back. It is your motorization that will lock and secure your swing gate.
Installation Tips:
Always check that your installation distances are included in the installation table. Installation distances determine the opening angle of your gate. Our Casanoov technical team is here to assist you.
Assembly instructions - KIT-000040
